Nandini Entreprenuer

1. Machine Size : ½” to 4” (15 mm to 100 mm)

2. Dies : ½”-¾”& 1”-2” & 2½”-4” universal dies set for Pipe Threading. (BSPT/NPT)

3. Spindle Speed : 22/10 RPM

4. Power Supply : 220V/380V

5. Motor Power : 900W/1100W (Single Phase)

6. Oiling System : Through die head, with integral oil reservoir

7. Pump : Self-priming constant flow

8. Thread Application : MS Pipe, GI Pipe & SS Pipe Optional

1. An induction motor ensures sound levels well when using

2. ¼”-2” universal Die Head; 2½”-4” receding die head allows cutting of tapered or straight BSPT / NPT

3. Self-Contained Oil System with adjustable flow control

4. One Operator can operate this machine easily

5. BSPT or NPT die can replace

6. It can Pipe Cutting, Threading & Reamering

Availability : Always Ex-stock

Delivery : The machine will dispatch within day after received 100% payment

Seaworthy Packing

1. Self-open die head.

2. ½”-¾”& 1”-2” & 2½” to 4” universal dies set for Pipe Threading. (BSPT/NPT)

3. Cutter: Capacity: 1/4”-4”(5 mm-100 mm) pipe

4. Cutting Wheel

5. Reamer

6.L-Key Set

7.Screw Driver

8.Machine Stand
