Threading Machine oil
Product Features
- Suitable for PE, PP, PVDF pipes butt welding integrated die casting aluminium clamps, steel base with cylinder, provides stable performance.
- Planning tool with separate switch prevents unintentional operation.
- Durable and long life HSS blade.
- Heating plate with high quality PTFE coating, enables swift temperature control.
Product Specifications
|
Model |
NEHBW160 |
NEHBW200 |
NEHBW250 |
NEHBW315 |
|
Welding Ranges (mm) |
63-160 |
63-200 |
63-250 |
63-315 |
|
Standard Reducers (mm) |
63-75-90-110-125-140-160 |
63-75-90-110-125-140-160-180-200 |
63-75-90-110-125-140-160-180-200-225-250 |
63-75-90-110-125-140-160-180-200-225-250-280-315 |
|
Power Supply |
220V/50Hz, 1 PH |
220V/50Hz, 1 PH |
220V/50Hz, 1 PH |
220V/50Hz, 1 PH |
|
Total Power |
3.25KW |
3.55KW |
4.15KW |
4.95KW |
|
Heating Plate |
1.5KW |
1.8KW |
2.3KW |
3.1KW |
|
Planning Tool |
1.0KW |
1.0KW |
1.1KW |
1.1KW |
|
Hydraulic Station |
0.75KW |
0.75KW |
0.75KW |
0.75KW |
|
Pressure Adjusting Range |
0-16MPa |
0-16MPa |
0-16MPa |
0-16MPa |
|
Max Temperature of Heating Plate |
270°C |
270°C |
270°C |
270°C |
|
Temperature Deviation |
+5°C |
+5°C |
+5°C |
+5°C |
