Product Specification
| Machine Size | ½” to 2” (12 mm to 50 mm) |
|---|---|
| DIES | ½”to ¾”& 1” to 2” universal dies set for Pipe Threading. (BSPT/NPT) |
| Thread Application | MS Pipe, GI Pipe & SS Pipe Optional |
| Spindle Speed | 40 RPM |
| Power Supply | 220V/ 50/60 Hz |
| Motor Power | 1150W (Single Phase) |
| Oiling System | Through die head, with integral oil reservoir |
| Pump | Self-priming constant flow |
Product Features
1. Heavy duty proven performance
2. Lightweight, Portable Design
3. Fast transport and set-up
4. Self-Contained Oil System with adjustable flow control.
5. Self-open die head and automatically threading length setting
6. One Operator can operate this machine easily
7. BSPT or NPT die can replace
Standard Accessories
• Self-open die head.
• ½”-¾”& 1”-2” universal dies set for Pipe Threading. (BSPT/NPT)
• Cutter: Capacity: 1/2”-2”(12 mm-50 mm) pipe
• Cutting Wheel
• Reamer
• L-Key Set
• Screw Driver
• Machine Stand
