Product Specification
|
Machine Size |
¼” to 1” |
|
Length of Bed |
44” |
|
Width of Bed |
11” |
|
Height of Bed |
11” |
|
Length of Pedestal Box |
44” |
|
Width of Pedestal Box |
18” |
|
Height of Pedestal Box |
20” |
|
Length of Slide |
17” |
|
Width of Slide |
11” |
|
Height of Slide |
3” |
|
Length of Head |
14½” |
|
Width of Head |
11” |
|
Height of Head |
11½” |
|
Threading Length |
8” |
|
Motor |
02HP 1440 RPM |
Product Features
1. The Bar Threading Machine is use to cut the external threads on the bar with the help of Tangential chasers. Bar thread cutting Chaser is use as a cutter in machine. Bar remain still, Die head rotates. Different type of threads can be cut on the bar such as BSW, NPT, UNF, Metric, UNC, ACME, BSF Threads etc.
2. The Spindle Bore 40 mm fitted with Taper Bearing
3. All Gears are Tempered (Oil Seals)
4. Motor Pulley 12” Diameter, V-belt drive vice fitted with jaw
5. Superior Performance, High Precision
6. Longer Service Life,
7. The Machine can thread on all types Rod, TMT , Rebar and Pipes (only change the dies for pipe threading and rod
threading)
8. Machine can threading lengths up to 14” inches and maximum rod can put in this machine 6 Mtrs.
9. This is commercial use machine for mass production
10. This is available in single phase & 3 Phase. There is Two Speed – 60 & 90 RPM
